Motorcycle Desktop Wallpapers
2011 Harley-Davidson FLHR Road King
Motorcycle wallpapers, insurance information, review and specifications
2011 Harley-Davidson FLHR Road King
Click Thumbnail to download (size 1600 x 1200 pixels)
Motorcycle wallpapers, insurance information, review and specifications
2011 Harley-Davidson FLHR Road King
Click Thumbnail to download (size 1600 x 1200 pixels)
When the original Harley-Davidson Road King motorcycle was introduced in 1994, it didn't take long for it to obtain iconic status with heritage going back to the original 1965 Electra Glide model. It may look like a timeless boulevard cruiser, but it is also a fully equipped, long-distance tourer. The innovative Harley-Davidson Touring chassis is based on a single-spar, rigid backbone frame and a stout swingarm developed to withstand the demands of long-haul touring riders and today's powerful engines.
Model Highlights
NEW Security Package Option including factory-installed Harley-Davidson® Smart Security System with hands-free fob and Anti-lock Braking System (ABS)
NEW Sculpted seat for added comfort and easier straddling
NEW Paint color options and graphics
o Black powder-coated powertrain with chrome covers
o Chrome 2-1-2 dual exhaust with tapered mufflers
o Black, 28-spoke Cast Aluminum wheels with narrow whitewall tires
o Chrome, low profile fuel tank console with electronic speedometer
o Clean rear fender and low-mounted license plate module with LED illumination
o Deep FL front fender with trim
o Stainless steel, ergonomic handlebar
o One-piece, two-up Road King® seat
o Clear, large Lexan® quick-release detachable windshield
o Injection-molded hard saddlebags, 2.26 cu. ft. volume
o Large Hiawatha headlight and chrome nacelle
o Auxiliary passing lights
Key Harley-Davidson FLHR Road King Key Features
When the original Harley-Davidson® Road King® motorcycle was introduced in 1994, it didn't take long for it to obtain iconic status. Its heritage goes all the way back to the original 1965 Electra Glide® model. It may look like a timeless boulevard cruiser, but it is also a fully equipped, long-distance tourer.
The innovative Harley-Davidson® Touring chassis is based on a single-spar, rigid backbone frame and a stout swingarm developed to withstand the demands of long-haul touring riders and today's powerful engines.
o Rubber-mounted Twin Cam 96™ V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI) with heated O2 sensors and Electronic Throttle Control (ETC)
o 6-Speed Cruise Drive® transmission with integrated Isolated Drive System (IDS)
o Dunlop® "Multi-Tread" rear tire construction extends tire life by 25 percent
o Brembo® 4-piston front and rear caliper with dual front rotor brake system
o Air-adjustable rear shocks
o Full-length rider footboards
o Height-adjustable passenger footboards
o Six-gallon fuel tank
o Optional Anti-lock Braking System (ABS)
o Optional electronic cruise controla
Specifications
U.S. MSRP - Vivid Black $16,999. Solids $17,399. Two-Tones $17,769
DIMENSIONS
Length 95.0 in. (2413 mm)
Overall Width 37.4 in. (950 mm)
Overall Height 55.1 in. (1400 mm)
Seat Height:
• Laden2 26.5 in. (673 mm)
• Unladen 28.0 in. (711 mm)
Ground Clearance 5.1 in. (130 mm)
Rake (steering head) 26°
Fork Angle 29.2°
Trail 6.69 in. (170 mm)
Wheelbase 63.5 in. (1613 mm)
Tires (Dunlop® Harley-Davidson Series, bias narrow whitewall):
• Front – D408F NW 130/80B17 65H
• Rear – D407 NW 180/65B16 81H
Fuel Capacity 6.0 gal. (22.7 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 4.0 qts. (3.8 L)
Transmission Capacity 1.0 qts.
Primary Chain
Case Capacity3 1.4 qts.
Weight:
• As Shipped 775 lbs. (351.5 kg)
• In Running Order 812 lbs. (368.3 kg)
• Gross Vehicle Weight Rating 1360 lbs. (616.9 kg)
• Gross Axle Weight Rating
• Front 500 lbs. (226.8 kg)
• Rear 927 lbs. (420.5 kg)
ENGINE
Engine4 Air-cooled, Twin Cam 96™
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Bore x Stroke 3.75 in. x 4.38 in. (95.3 mm x 111.3 mm)
Displacement 96 cu. in. (1584 cc)
Compression Ratio 9.2:1
Fuel System4 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Fiberglass, washable
Lubrication System Pressurized, dry-sump
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/68 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
U.S. Gear Ratios (overall):
• 1st 9.593
• 2nd 6.65
• 3rd 4.938
• 4th 4.0
• 5th 3.407
• 6th 2.875
CHASSIS
Frame Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded
Swingarm Mild steel; two-piece drawn and welded section; forged junctions; MIG welded
Front Forks 41.3 mm telescopic
Rear Shocks Air-adjustable
Wheels5 (Chrome, Profile Laced Aluminum option): Black, 28-spoke Cast Aluminum
• Front 17 in. x 3 in. (432 mm x 76 mm)
• Rear 16 in. x 5 in. (406 mm x 127 mm)
Brakes:
• Caliper Type 32 mm, 4-piston fixed front and rear
• Rotor Type (diameter x width): Patented, fixed rotors
• Front (dual) 11.81 in. x .2 in. (300 mm x 5 mm)
• Rear 11.81 in. x .28 in. (300 mm x 7 mm)
• Anti-lock Braking System (option) Available
Suspension Travel:
• Front Wheel 4.6 in. (117 mm)
• Rear Wheel 3 in. (76 mm)
Engineered for Sidecar Use Available
PERFORMANCE
Engine Torque6 (per SAE J1349):
• North America 92.6 ft. lbs. @ 3500 RPM (126 Nm @ 3500 RPM)
Lean Angle:
• Right 33°
• Left 31°
Fuel Economy7
(EPA urban/highway test)
35/54 mpg (6.70/4.40 L/100 km)
ELECTRIC
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 28-amp/hour, 370 cca
Charging Three-phase, 50-amp system (585W @ 13V, 2000 RPM, 650W max power @ 13V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
• Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
• Tail/Stop Lights 8W/28W (5W/21W)
• Turn Signal Lights 28W (21W) self-canceling
• Indicator Lamps - High beam, running lights, front fender running lights, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system8 (optional), 6-speed, low fuel warning, cruise control (optional), ABS (optional)
COLOR OPTIONS
Solids
• Vivid Black
• Sedona Orange
Two-Tones
• Cool Blue Pearl/Vivid Black
• Merlot Sunglo/Vivid Black
WARRANTY
Warranty9 24 months (unlimited mileage)
Service Interval First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter
Model Highlights
NEW Security Package Option including factory-installed Harley-Davidson® Smart Security System with hands-free fob and Anti-lock Braking System (ABS)
NEW Sculpted seat for added comfort and easier straddling
NEW Paint color options and graphics
o Black powder-coated powertrain with chrome covers
o Chrome 2-1-2 dual exhaust with tapered mufflers
o Black, 28-spoke Cast Aluminum wheels with narrow whitewall tires
o Chrome, low profile fuel tank console with electronic speedometer
o Clean rear fender and low-mounted license plate module with LED illumination
o Deep FL front fender with trim
o Stainless steel, ergonomic handlebar
o One-piece, two-up Road King® seat
o Clear, large Lexan® quick-release detachable windshield
o Injection-molded hard saddlebags, 2.26 cu. ft. volume
o Large Hiawatha headlight and chrome nacelle
o Auxiliary passing lights
Key Harley-Davidson FLHR Road King Key Features
When the original Harley-Davidson® Road King® motorcycle was introduced in 1994, it didn't take long for it to obtain iconic status. Its heritage goes all the way back to the original 1965 Electra Glide® model. It may look like a timeless boulevard cruiser, but it is also a fully equipped, long-distance tourer.
The innovative Harley-Davidson® Touring chassis is based on a single-spar, rigid backbone frame and a stout swingarm developed to withstand the demands of long-haul touring riders and today's powerful engines.
o Rubber-mounted Twin Cam 96™ V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI) with heated O2 sensors and Electronic Throttle Control (ETC)
o 6-Speed Cruise Drive® transmission with integrated Isolated Drive System (IDS)
o Dunlop® "Multi-Tread" rear tire construction extends tire life by 25 percent
o Brembo® 4-piston front and rear caliper with dual front rotor brake system
o Air-adjustable rear shocks
o Full-length rider footboards
o Height-adjustable passenger footboards
o Six-gallon fuel tank
o Optional Anti-lock Braking System (ABS)
o Optional electronic cruise controla
Specifications
U.S. MSRP - Vivid Black $16,999. Solids $17,399. Two-Tones $17,769
DIMENSIONS
Length 95.0 in. (2413 mm)
Overall Width 37.4 in. (950 mm)
Overall Height 55.1 in. (1400 mm)
Seat Height:
• Laden2 26.5 in. (673 mm)
• Unladen 28.0 in. (711 mm)
Ground Clearance 5.1 in. (130 mm)
Rake (steering head) 26°
Fork Angle 29.2°
Trail 6.69 in. (170 mm)
Wheelbase 63.5 in. (1613 mm)
Tires (Dunlop® Harley-Davidson Series, bias narrow whitewall):
• Front – D408F NW 130/80B17 65H
• Rear – D407 NW 180/65B16 81H
Fuel Capacity 6.0 gal. (22.7 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 4.0 qts. (3.8 L)
Transmission Capacity 1.0 qts.
Primary Chain
Case Capacity3 1.4 qts.
Weight:
• As Shipped 775 lbs. (351.5 kg)
• In Running Order 812 lbs. (368.3 kg)
• Gross Vehicle Weight Rating 1360 lbs. (616.9 kg)
• Gross Axle Weight Rating
• Front 500 lbs. (226.8 kg)
• Rear 927 lbs. (420.5 kg)
ENGINE
Engine4 Air-cooled, Twin Cam 96™
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Bore x Stroke 3.75 in. x 4.38 in. (95.3 mm x 111.3 mm)
Displacement 96 cu. in. (1584 cc)
Compression Ratio 9.2:1
Fuel System4 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Fiberglass, washable
Lubrication System Pressurized, dry-sump
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/68 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
U.S. Gear Ratios (overall):
• 1st 9.593
• 2nd 6.65
• 3rd 4.938
• 4th 4.0
• 5th 3.407
• 6th 2.875
CHASSIS
Frame Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded
Swingarm Mild steel; two-piece drawn and welded section; forged junctions; MIG welded
Front Forks 41.3 mm telescopic
Rear Shocks Air-adjustable
Wheels5 (Chrome, Profile Laced Aluminum option): Black, 28-spoke Cast Aluminum
• Front 17 in. x 3 in. (432 mm x 76 mm)
• Rear 16 in. x 5 in. (406 mm x 127 mm)
Brakes:
• Caliper Type 32 mm, 4-piston fixed front and rear
• Rotor Type (diameter x width): Patented, fixed rotors
• Front (dual) 11.81 in. x .2 in. (300 mm x 5 mm)
• Rear 11.81 in. x .28 in. (300 mm x 7 mm)
• Anti-lock Braking System (option) Available
Suspension Travel:
• Front Wheel 4.6 in. (117 mm)
• Rear Wheel 3 in. (76 mm)
Engineered for Sidecar Use Available
PERFORMANCE
Engine Torque6 (per SAE J1349):
• North America 92.6 ft. lbs. @ 3500 RPM (126 Nm @ 3500 RPM)
Lean Angle:
• Right 33°
• Left 31°
Fuel Economy7
(EPA urban/highway test)
35/54 mpg (6.70/4.40 L/100 km)
ELECTRIC
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 28-amp/hour, 370 cca
Charging Three-phase, 50-amp system (585W @ 13V, 2000 RPM, 650W max power @ 13V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
• Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
• Tail/Stop Lights 8W/28W (5W/21W)
• Turn Signal Lights 28W (21W) self-canceling
• Indicator Lamps - High beam, running lights, front fender running lights, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system8 (optional), 6-speed, low fuel warning, cruise control (optional), ABS (optional)
COLOR OPTIONS
Solids
• Vivid Black
• Sedona Orange
Two-Tones
• Cool Blue Pearl/Vivid Black
• Merlot Sunglo/Vivid Black
WARRANTY
Warranty9 24 months (unlimited mileage)
Service Interval First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter
